Inclination Sensor

LTS6

CAN2.0B Tilt Sensor

Six installation methods
Resolution 0.1°
Output method: CAN 2.0B
High vibration resistance >2000g

Product Introduction

The LTS6 series is a new generation of dynamic measurement-type, small-volume MEMS tilt sensors launched by Ruiguan Technology , capable of stably measuring the attitude of moving vehicles. This product incorporates a dual-channel gravity tilt unit, measuring static gravitational acceleration and converting it into tilt angle changes, thereby obtaining the sensor's output tilt and pitch angles relative to the horizontal plane . The output interface is CAN 2.0B. Thanks to the built-in MCU control system, the sensor's output linearity is double-corrected, compensating for the accuracy loss caused by insufficient correction in analog products .

This product employs a non-contact measurement principle, providing real-time output of the current attitude tilt angle. It is easy to operate and eliminates the need to locate two mounting surfaces with relative changes. Suitable for both static and dynamic measurement scenarios, this product is a reliable choice for industrial automation control and platform attitude measurement . It also possesses strong resistance to external electromagnetic interference. It can operate stably for a long time in harsh industrial environments.

Performance Parameters

HTS6	condition	Parameter Unit
Measurement range		±90°	±35°
Measuring axis		Xaxis/Yaxis
Resolution1)		0.1	°
Static temperature	@25℃	±0.3	°
Dynamic temperature	@25℃	±0.8
Zero-point temperature coefficient3)	-40～85℃	±0.01	°/℃
Sensitivity temperature coefficient4)	-40～85℃	≤10 0	ppm/℃
Power-on startup time		1.5	S
Response frequency		0.05	S
Output signal	CAN2.0B
Electromagnetic compatibility	According toEN61000andGBT17626
Mean Time Between Failures (MTBF)	≥99999hours/time
Insulation resistance	≥100megohms
Impact resistance	100g@11ms, triaxial(half-sine wave)
Vibration resistance	10grms10~1000Hz
Protection level	IP67
Cable	Standard configuration includes a1-meterdurable, oil-resistant, wide temperature range, shielded cable wire
Size	L64.5×W50×H18.5mm
weight	≤100g (excluding cable)

Product Dimensions
